Arduino Nano Ch340 Soldered Board Type C
The Arduino Nano is a compact microcontroller board based on the ATmega328P, featuring 30 soldered male header pins for easy prototyping. This variant includes a CH340 USB-to-serial converter and a USB Type-C port, offering modern connectivity and reliable programming.
⚙️ Key Technical Details:
• Microcontroller: ATmega328P, 8-bit AVR, 16 MHz clock speed
• USB Interface: CH340G IC handles serial communication via USB Type-C
• Power Supply:
• VIN: 6–12V input
• 5V & 3.3V: Regulated outputs for peripherals
• USB VBUS: Supplies 5V when connected via Type-C
• I/O Pins:
• Digital: 14 (D0–D13), including PWM on D3, D5, D6, D9, D10, D11
• Analog: 8 (A0–A7), 10-bit ADC resolution
• Serial: UART (TX: D1, RX: D0), SPI (D10–D13), I2C (A4: SDA, A5: SCL)
• Flash Memory: 32 KB (2 KB used by bootloader)
• SRAM: 2 KB
• EEPROM: 1 KB
🔌 Type-C Connector Notes:
• Supports USB 2.0 data lines (D+/D−) routed to CH340
• VBUS and GND provide power input
• CC pins typically tied to ground via pull-down resistors for cable orientation
This Nano variant is ideal for embedded systems, sensor networks, and compact automation projects—especially where modern USB compatibility and robust serial communication are essential.
₹285.00 exc. GST
The Arduino Nano is a powerhouse in a tiny package—perfect for compact, creative, and practical builds. Here are some standout project ideas you can explore:
🔧 Practical Electronics Projects
- Smart Door Lock: Use a servo motor, keypad, and Nano to control access.
- Temperature & Humidity Logger: Combine with a DHT11/DHT22 sensor and microSD module.
- Mini UPS System: Monitor battery voltage and switch to backup power using relays.
- Automatic Plant Watering: Soil moisture sensor + water pump = stress-free gardening.
🎮 Interactive & Fun Builds
- Gesture-Controlled Robot: Pair with an accelerometer and RF modules.
- Mini Synthesizer: Use a piezo buzzer and potentiometers to create tones.
- LED Dice or Game Spinner: Great for board game enhancements.
- Tiny Arcade Machine: OLED display + buttons for retro gaming.
📡 IoT & Communication Projects
- Wi-Fi Weather Station: Add an ESP8266 or ESP01 module for cloud updates.
- Bluetooth Home Automation: Control lights or appliances via smartphone.
- RFID Attendance System: Track entries with RFID tags and serial logging.
🧠 Sensors & Automation
- Motion-Activated Light: PIR sensor triggers LEDs or relays.
- Ultrasonic Distance Meter: Display measurements on an LCD.
- Gas Leak Detector: MQ-series sensors for safety alerts.
- Line-Following Robot: IR sensors and motor drivers for autonomous movement.
🖼️ Creative & Artistic Ideas
- Animated LED Art: Use WS2812B or NeoPixel strips for dynamic visuals.
- Mood Lamp: RGB LEDs controlled by touch or ambient light.
- Digital Hourglass: LEDs simulate sand flow with a tilt sensor.
If you tell me your preferred theme—home automation, robotics, wearable tech, or something anime-inspired—I can help you design a project tailored to your style.
