Finger Print Sensor AS608
Compact and reliable AS608 fingerprint sensor module for biometric identification and security projects. Features high‑accuracy fingerprint recognition, fast response time, and built‑in storage for multiple fingerprints. Ideal for Arduino, Raspberry Pi, access control systems, and IoT security applications.
Technical Specifications:
- Model: AS608 Fingerprint Sensor
- Interface: UART (serial communication)
- Operating Voltage: 3.3V – 5V DC
- Fingerprint Capacity: ~100–120 fingerprints (varies by module)
- Recognition Speed: <1 second
- Accuracy: High recognition rate with false rejection/acceptance control
- Dimensions: Compact design for easy integration
- Applications: Door locks, attendance systems, Arduino/Raspberry Pi projects, IoT security devices
₹900.00 exc. GST
Based on 0 reviews
Be the first to review “Finger Print Sensor AS608”
