Johnson Gear Motor 10Rpm Grade B

The Johnson Geared Motor (Grade B) 10 RPM is a reliable and cost-effective DC motor commonly used in various applications. Here’s a detailed overview of its features, setup, and applications:

Key Features
Base Motor RPM: 18000 RPM (reduced to 10 RPM with gearbox)

Operating Voltage: 6-18 V DC

Rated Voltage: 12 V DC

Rated Torque: 11.7 kg-cm at 10 RPM

Stall Torque: 46 kg-cm

Dimensions: The gearbox has diameter of 37 mm , shaft has a diameter of 6 mm and the shaft length is 30 mm , the motor has the dimension of 27 mm making it compact and easy to integrate into various projects.

Shaft: Side shaft (off-centered), equipped with metal bushes for wear resistance

Mounting: Six M3 mounting holes for easy installation

Applications
Pan/Tilt Cameras: Ideal for smooth and precise movement.

Auto Shutter: Used in automated photography equipment.

Welding Machines: Provides consistent and controlled motion.

Household Appliances: Commonly found in devices like grills, ovens, and cleaning machines.

Robotic Platforms: Suitable for educational robots and automation projects.

Coin Refund Devices: Used in vending machines and coin-operated devices The Johnson Geared Motor (Grade B) 10 RPM is a versatile and affordable motor suitable for a wide range of applications. Its compact size and reliable performance make it a popular choice for hobbyists and professionals alike.

Special Note
We are selling 2 types of Johnson Motors as “Johnson Geared Motor – Grade A Quality” and “Johnson Geared Motor – Grade B“, the only difference between them is the quality of materials used for manufacturing the motor. All other specification including look, dimensions, working etc. are same. The “Grade A Quality” motors shows slightly more torque count than “Grade B” Johnson Motors and hence dominates “Grade B” quality motors.
