MLX90614 Contactless Temperature Sensor Module
The MLX90614 is a high‑accuracy non‑contact infrared temperature sensor housed in a compact TO‑39 metal can package. It provides factory‑calibrated temperature readings, supports SMBus/I²C digital output, and offers wide measurement ranges suitable for Arduino, ESP32, Raspberry Pi, robotics, medical devices, and industrial temperature monitoring.
Technical Specifications:
- Model: MLX90614 IR Thermometer Module
- Sensor Type: Non‑contact IR thermopile with onboard signal conditioning
- Package: TO‑39 metal can
- Operating Voltage: 3V to 5V
- Temperature Range:
- Sensor temperature: −40°C to +125°C
- Object temperature: −70°C to +380°C
- Accuracy: ±0.5°C (0°C to +50°C range)
- Resolution: 0.02°C
- Interface: SMBus/I²C digital output + optional PWM output
- Field of View (FOV): Multiple options (e.g., 35°, 10°, 5° depending on variant)
- Current Consumption: ~1.4 mA (typical)
- Applications: Non‑contact temperature measurement
HVAC systems
Robotics
Medical thermometers
Industrial monitoring
Movement detection
₹700.00 exc. GST
