Servo Motor MG 996-360*

The L298N motor driver module is a high-power driver designed to control DC motors and stepper motors. It features a double H-bridge design, allowing for direction and speed control of two DC motors or one stepper motor. The module supports up to 2A of current and 25W of power.

The Johnson Geared Motor (Grade B) 100 RPM is a reliable and efficient DC motor designed for various applications requiring moderate speed and high torque.

Here are its key features:

Base Motor RPM: 18000 RPM (reduced to 100 RPM with gearbox)

Operating Voltage: 6-18 V DC

Rated Voltage: 12 V DC

Rated Torque: 5.5 kg-cm at 100 RPM

Stall Torque: 22 kg-cm

Dimensions: The gearbox has diameter of 37 mm , shaft has a diameter of 6 mm and the shaft length is 30 mm , the motor has the dimension of 27 mm making it compact and easy to integrate into various projects.

Shaft: Side shaft with metal bushes for wear resistance

Mounting: Six M3 mounting holes

Applications
Pan/Tilt Cameras: Smooth and precise movement for surveillance systems.

Household Appliances: Used in devices like grills, ovens, and cleaning machines.

Robotic Platforms: Suitable for educational robots and DIY projects.

Coin Refund Devices: Used in vending machines and coin-operated devices.

Special Note
We are selling 2 types of Johnson Motors as “Johnson Geared Motor – Grade A Quality” and “Johnson Geared Motor – Grade B“, the only difference between them is the quality of materials used for manufacturing the motor. All other specification including look, dimensions, working etc. are same. The “Grade A Quality” motors shows slightly more torque count than “Grade B” Johnson
