Turbidity Sensor with ADC Circuit
A turbidity sensor module with an ADC (Analog-to-Digital Converter) circuit detects water clarity by measuring light scattering from suspended particles and converts the analog signal into a digital output for microcontroller interfacing. It typically includes an infrared LED and photodiode pair, signal conditioning circuitry, and an onboard ADC to provide stable, calibrated digital readings for water quality monitoring applications.
Some basic specifications are:
- Working voltage: 5.00V DC
- Working current: 40mA (MAX)
- Response time: <500ms
- Insulation resistance: 100MΩ (Min)
- Analogue output: 0~4.5V;
- Digital output: high/low-level signal (the corresponding threshold can be selected by adjusting the potentiometer)
- Operating temperature: -20℃~90℃
- Module size: 38.6mm*22.1mm
₹600.00 exc. GST
Based on 0 reviews
Be the first to review “Turbidity Sensor with ADC Circuit”
