Servo Motor Deao 20kg-180*
High‑torque Deao 20kg 180° servo motor with metal gears for durability and precision. Provides smooth 180° rotation, stable performance, and long service life. Ideal for robotics, RC cars, planes, boats, and Arduino/DIY automation projects.
Technical Specifications:
- Model: Deao 20kg 180° Servo Motor
- Torque: ~20 kg·cm at 6.8V
- Rotation Angle: 180°
- Gear Type: Metal gears for strength and durability
- Operating Voltage: 4.8V – 6.8V DC
- Speed: ~0.16 sec/60° at 6.8V
- Connector: Standard 3‑pin (PWM control)
- Dimensions: ~40 × 20 × 40 mm (varies slightly by batch)
- Applications: RC cars, planes, boats, robotics, Arduino projects, automation systems
₹975.00 exc. GST
